Send InquiryCarrier Pipe Casing Spacers
Carrier Pipe Casing Spacers Specification
- Tolerance
- 2 mm
- Connection Type
- Slip-On / Bolt-On
- Coating Type
- Polyethylene / Epoxy (Optional)
- Thread Type
- Non-threaded
- Temperature Range
- -40C to +80C
- Tensile Strength
- 22 MPa
- Flexibility
- Rigid
- Yield Strength
- 15 MPa
- Sealing Type
- Non-sealing
- Diameter
- Varies as per Pipe Specification
- Product Type
- Carrier Pipe Casing Spacers
- Material
- Other
- Connection
- Interlocking / Snap-on
- Shape
- Other
- Standard
- ASTM D2487, AWWA C200
- Surface Treatment
- UV-Resistant Coating / Polished
- Outer Diameter
- 63 mm to 1200 mm
- Section Shape
- Cylindrical
- Length
- Standard Length 200 mm / Customizable
- Thickness
- 8 mm to 12 mm
- Color
- Black / Grey
- Usage
- Pipe Support and Insulation in Casings
- Rated Pressure
- Up to 16 Bar
- Material Grade
- HDPE PE80 / PE100, Stainless Steel 304/316
- Application
- Water, Oil, Gas Piping, Sewer, Ducts
- Packaging Type
- Carton box or bulk bag
- Dielectric Properties
- Excellent electrical insulation between carrier and casing pipe
- Corrosion Resistance
- High resistance to acids, alkalis, salts, and electrolytic corrosion
- Number of Runners
- 2, 4, or 6 runners per spacer (as per size)
- Spacer Height
- Available from 25 mm to 75 mm
- Weight per Piece
- From 120 g to 2.5 kg (depending on size)
- Installation Method
- Tool-free push-fit or bolted installation
- Maximum Load Capacity
- Up to 5000 kg
- Maintenance
- Maintenance-free
About Carrier Pipe Casing Spacers
Although casing spacers play a small part in the installation process of a water or sewer carrier pipe, the part they play is an important one.
Also known as casing insulators, theyre able to improve a carrier pipes performance, reliability, and life-cycle. In addition, insulators ensure accurate alignment, provide support, and reduce pipe installation time.
Exceptional Corrosion Resistance for Longevity
Built using premium HDPE or stainless steel, these casing spacers are highly resistant to acids, alkalis, salts, and electrolytic corrosion. Their durability makes them ideal for harsh environments, significantly enhancing the service life of carrier pipelines.
Efficient, Maintenance-Free Installation
Installation is fast and straightforward, requiring no special tools. With a convenient push-fit or bolt-on method and interlocking connections, these spacers lower both labor costs and downtime-making them suitable for on-site or retrofit applications.
Superior Pipe Protection and Insulation
With dielectric properties and strong UV-resistant coatings, these spacers safeguard pipelines from electrical and environmental hazards. The variety of runner options ensures tailored pipe support, preventing metal-to-metal contact and minimizing wear.
FAQ's of Carrier Pipe Casing Spacers:
Q: How are Carrier Pipe Casing Spacers installed on the pipeline?
A: Carrier Pipe Casing Spacers feature a user-friendly, tool-free push-fit or bolted installation method. The connection can be interlocking or snap-on, depending on the model, facilitating quick assembly and secure placement inside the casing.Q: What applications are Carrier Pipe Casing Spacers suitable for?
A: These spacers are well-suited for supporting and insulating carrier pipes in water supply, oil and gas pipelines, sewer lines, and cable ducts. Their robust construction and resistance make them ideal for industrial, municipal, and infrastructure projects.Q: When should you choose a spacer height between 25 mm and 75 mm?
A: The appropriate spacer height depends on the required clearance between the carrier and casing pipe, as well as pipeline diameter and application. Custom options accommodate various installation needs and ensure optimal protection and alignment.Q: Where are these spacers most commonly used in India?
A: Carrier Pipe Casing Spacers are widely used under roads, railways, and water crossings, as well as in urban infrastructure projects across India due to their strength, corrosion resistance, and compliance with ASTM D2487 and AWWA C200 standards.Q: What are the benefits of the dielectric and corrosion-resistant properties?
A: Excellent dielectric properties prevent electrical conduction between the carrier and casing pipes, protecting against electrolytic corrosion. High resistance to environmental chemicals extends system longevity, reducing long-term maintenance costs.Q: How do you maintain these pipe casing spacers after installation?
A: These spacers are designed to be maintenance-free. Their durable materials and UV-resistant coatings minimize degradation, making routine checks unnecessary, which enhances operational reliability over extended periods.Tell us about your requirement
